Black Silicon Carbide

Black Silicon Carbide

Black Silicon Carbide (SiC), also known as Carborundum, is a semiconductor containing silicon and carbon with chemical formula SiC. The Silicon Carbide crude is produced by combining silica sand and carbon in an Acheson graphite electric resistance...
Products Inquiry


Product Introduction

     Black silicon carbide is well noted as one of nice artificial material , also named emery grain or carborundum , which is produced by high-temperature smelting of electric furnaces such as quartz sand, petroleum coke (or blind coal), and wood chips, it can be called gold steel sand or refractory sand. hexagonal crystals, specific gravity of 3.20 ~ 3.25, microhardness of 2840 ~ 3320kg / mm2.

Main Application

        Solar wafer, semiconductor wafer and quartz chip wire sawing and lapping, bonded and coated abrasive tools: stone polishing; processing metal and non-ferrous metal with low tensile strength, such as: gray pig iron, brass, aluminum, stone, leather and rubber.


Grit Size Chemical Composition % (by weight)
12#-90# ≥98.50 ≤0.15 ≤0.15
100#-220# ≥98.50 ≤0.15 ≤0.15
240#-600# ≥98.00 ≤0.15 ≤0.15
800#-1000# ≥98.00 ≤0.20 ≤0.20
1200#-1500# ≥97.50 ≤0.20 ≤0.20

Standard: FEPA – F (bonded abrasive application), FEPA - P (coated abrasive application), JIS Standard.
Grit Available: F12 – F220 (Macro), F240 – F1500 (Micro powder) P24 – P220 (Macro), P240 – P2500 (Micro powder) JIS 12# – 4000#
For refractory: 0-1mm, 1-3mm, 3-5mm, 0-10mm, -70F, -100F, -325F, C-Dust.

Other grain sizes on requests are available.
